Heavy Wrecker Rotator have a GVWR of at least 30,000kgs, the minimum cab-to-axle length of 6460mm ,mounted a double boom, and double planetary winches. These trucks are the olympians of towing. For increased driver convenience, features such as tailboard L-arm storage, easy-access safety chain pockets and easy-to-operate dual control stations along with wheel lift system are just a few of the many reasons why you should contact us as a distributor.
Built to meet the toughest demands of towing and recovery work, our new HOWO Heavy Wrecker Rotator is powered by commercial-grade 6.7-liter Cummins turbo diesel engine and manual transmission to provide improved comfort.
The over-built boom technology is feature a unique patented roller system that allows the boom to travel up to 60”.It has a double 16000kgs winch and a hydraulic two stage extendable boom that could reach 8000mm.Rated at 16 tons retracted and a remarkable 12 ton extended.
The underlift designed for recovery operations as well as the availability of the self loading wheel lift.It is specifically designed to undertake various recovery tasks which involve extraction of disabled casualty vehicles, overturned vehicles, handing operations and towing (both straight and suspended broken down vehicles) has been inducted in operations after rigorous trials in deserts terrains, mountains, high altitude areas and plains.
WORM GEAR WINCH
We manufacture this unit with two 8,000kg worm gear winches and coupled it with a 10-ton capacity extendable boom, optional frame fork attachment and optional manual outside controls for the recovery boom is more than just another tow truck. The two winches hold 150ft of cable on each.
STEEL MODULAR BODY
The 4 compartments tri-axles steel body fabricated with professional and modularized, different assemblies are precision manufacturing that ensured the multi compatibilities.LED tool compartment lighting bar,keyless lock and unlock lift fork storage box compartment,chain storage comparment and tailboard fork, chain storage compartment.
The hydraulic oil pipe fabricated from high-pressure galvanized steel, pressure resistance, well thermal performance, attractive looks, durable use, the service life could be synchronized with the super body. Hydraulic fittings is bite type rigid connectors(Germany), has been greatly reduced the phenomenon of interface oil leakage, the service life could be synchronized with the super body too.
Independent full size C typed LED light bar, fully consider the wrecker lights disturbance the operator’s sights during loading transporting, CSCTRUCK re-customize the appropriate assembly light bar. The C typed arc design, ally with the typical metal forming technology, well integrated the alarm lights create an elegant light pylon.
1. We are the manufacturer.
2. OEM is OK.
3. ISO certificate.
PACKAGING & SHIPPING,TRADE TERMS
By sea :/Nude/ Ro-ro ship / Bulk transport / Container packing / SKD / etc.;
Customers pointed freight forwarders or negotiable shipping methods;
Delivery Time: 10-25 days.
Payment Terms: T/T, L/C, 30% deposits; 70% balance before delivery,
MOQ: 1 UNIT
Warranty: 1 year or 20000km
Chassis Make: SINOTRUK,
Chassis Model: HOWO 8*4;
Engine Make: Weichai Power,
Engine Horsepower 420hp,
Fuel Type: Diesel;
Transmission: Manual FAST brand 12speed ;
Axle Ratio: 5.13;
GVWR: 30000kg ;
Front Axle Weight Rating: 7000kg double axles,
Rear Axle Weight Rating: 13000kg double ;
Cab to Axle: 6460mm,
Wheel Base: 4350mm+1310mm+1310mm;
Suspension: Leaf Spring ; Tires: 12R22.5 ;Wheels: Steel.
AM/FM/CD Stereo Radio ;
Cloth High Back Driver Seat ;
Split Cloth 2 Man High Back Passengers Seat ;
Tilt Wheel optional
Rubber Flooring w/Rubber Floor Mats
Jumper Cable Kit w/Cable
Swing Out Mirrors w/Convex Mirrors
Cab Roof Marker Lights Color: Yellow
