Large Rotator Tow Truck

•70 Ton Rotator
•60 Ton Rotator
•50 Ton Rotator
•40 Ton Rotator

Description

Structural Features:

1. Special Chassis, Reasonable Structure, Excellent Performance, Powerful Function

Strongly cooperated with chassis manufacturer to create a dedicated special vehicle chassis, csctruck has established cooperative relations with many special truck chassis manufacturers such as Mercedes-Benz, Volvo, Shacman, Sinotruk, Faw, Dongfeng, and Foton. A series of special truck chassis have been custom-developed, laying a solid foundation for manufacturing high-quality wrecker products.


2. Rotator Body System, Reliable Quality, Smarter, Simple and safe operation

Equipped with a 360° continuously rotation boom, the heavy-duty wrecker can also use the boom's swinging, telescoping, and swinging to haul or hang the accident vehicle from the roadbed and near the roadbed to the road surface.



3. Lifting mechanism, powerful function and excellent performance

The lifting function is the most important function of the wrecker. It uses the expansion, lifting, and folding of the supporting arm to lift the damaged vehicle from the front or rear, and then drags the vehicle away from the scene. The bracket of the wrecker has various structural forms, and it can generally hold the axle, wheel, leaf spring, frame of the accident car, etc., which is convenient for assembly and disassembly.


4. Hydraulic system, reliable performance and high efficiency

Rotary crane type wrecker truck is fully hydraulically driven, which integrates multiple functions such as lifting, lifting, towing, and traction. Adopt imported special balancing valve, this valve has three functions of balancing, holding pressure and overload protection. Especially the overload protection function: when the set pressure is exceeded, it can overflow and unload in time, which is of great significance to limit the overload protection of each part and component of the wrecker. There are also various hydraulic locks in the hydraulic system, and the protection mechanism fails due to the failure of the hydraulic system under load to cause an accident.


5. Personalized Needs and Customization

The special operating environment requires applicable special customization. In order to meet the market demand, our company provides reasonable personalized modification programs, strengthens its functions on the original basis, and can also customize special restructuring programs according to customer needs.


Rotator Model Line


70 Ton Rotator Tow Truck



•8x4, 10x4 Truck Chassis
•300-500hp Diesel Engine
•3-4 stage Boom System
•Underlift Capacity 18/20T
•Boom Capacity 70T
•Boom Max Reach 15/17m

image image


image image

60 Ton Rotator Tow Truck


•8x4, 10x4 Truck Chassis
•300-500hp Diesel Engine
•Overall Size 11.15x2.5x3.6m
•Underlift Retracted Rating 16/18T

50 Ton HOWO Rotator Tow Truck

● 8×4 Truck Chassis
●300hp-400hp Engine
●Max Towing 50Ton
●Underlift Lifting 16Ton
●360˚Rotator Body
●Size 11.12×2.5×3.7m

image image

40 Ton Rotator Tow Truck

•6x4, 8x4 Truck
•270-400hp Engine
•3-stage Boom System
•Underlift Capacity 16T
•Boom Capacity 40T
•Boom Max Reach 12m


Vehicle Model

CSC5410TQZVDZ

CSC5317TQZZDZ5

CSC5437TQZZDZ

CSC5437TQZZDZ

Rotator Body

25T40DZ

16T30DZ

25T40DZ

28T50DZ

Wheelbase, mm

1995+4405+1370

1800+4600+1350

1800+4600+1350

1800+4600+1350

Under-lift Capacity, kg

25000

16000

25000

28000

Underlift at full extended, kg

8000

6000

8000

9000

Boom Lifting Capacity, kg

40000

30000

40000

50000

Boom Lifting Capacity at full extended, kg

18000

9500

18000

18000

Winch Nos.

2

2

2

2

Winch Capacity, kn

250

150

250

250
